Mini Wheel Loader
High Maneuverability：Boasts a high travel speed of 4.5 km/h and an exceptionally small turning radius of 570 mm, ensuring superior agility and efficiency in confined workspaces.
Powerful & Efficient Engine：Equipped with a reliable 33 HP Rato air-cooled engine, it delivers robust performance with high fuel efficiency (theoretical consumption: 10 L/h) using standard 92# gasoline.
Outstanding Lifting Capacity：Offers a maximum breakout force of 380 kg and a significant maximum working height of 3590 mm, enabling it to handle tough materials and reach considerable heights.
Product Introduction
The KRW232 is a compact and highly efficient engineering machine designed to deliver outstanding performance in confined workspaces. With a working weight of 1100 kg and a compact body length of just 1945 mm (without bucket), it offers remarkable maneuverability and stability. Its powerful Rato 33 HP air-cooled engine, running on standard 92# gasoline, ensures robust and reliable operation with a theoretical fuel consumption of only 10 L/h, making it both powerful and cost-effective for daily use.
This model excels in material handling and lifting tasks, featuring a generous bucket capacity of 0.16 m³ and a maximum breakout force of 380 kg. It achieves a notable maximum working height of 3590 mm and an unloading height of 1820 mm, allowing it to tackle a wide range of loading, digging, and lifting applications with ease. The optimized wheelbase of 801 mm contributes to its excellent balance and operational stability, even when working at full capacity.
Engineered for smooth and responsive operation, the KRW232 is equipped with a high-performance hydraulic system centered around the PGP532B62 main pump, which provides a maximum flow rate of 70 L/min. This ensures precise and powerful control of all hydraulic functions. Practical design features include durable 570 * 16 wheels for solid traction and ample 40L capacity for both the fuel and hydraulic oil tanks, supporting extended work cycles with minimal downtime, making it a dependable and productive partner on any job site.
Product Details
Full Opening Engine Cover The engine cover can be tilted upward to expose the majority of the engine, enabling easier access to its components for maintenance and service. |
|
Advanced Cooling System Equipped with an optimized radiator, this system accelerates heat dissipation to protect critical accessories and maintain peak performance under demanding conditions. |
|
Variable Speed Travel Motor This travel motor supports high and low speeds, delivering enhanced power for flexible operational performance. |
|
New LED Boom Work Light featuring LED headlights designed to replace traditional halogen headlights. |
|
RATO Engine Powerful and dependable, the KTT23 Rato gasoline engine delivers superior horsepower and performance. It ensures low noise and vibration levels, along with excellent fuel efficiency. |
|
Reinforced Structure for Enhanced Safety and Efficiency Featuring thickened plates and precision welding, this design delivers greater strength, ensuring safer and more efficient operation. |
|
Product Specifications
| Model Information Configuration Status √Standard, △Optional , ×None | KRW232 | |
| Basic Performance Parameters | ||
| Working Weight(kg) | 1100 | |
| Bucket capacity(m³) | 0.16 | |
| Travel high speed(Km/h) | 4.5 | |
| Maximum lifting force (Kg) | 380 | |
| A Maximum working height(mm) | 3590 | |
| H Unloading height(mm) | 1820 | |
| L Wheelbase(mm) | 801 | |
| G Max. height unloading angle(°) | 40 | |
| Equipment Body | ||
| F Overall Length(mm) | 2580 | |
| E Overall Length(mm) (without bucket) | 1945 | |
| T Overall Width(mm) | 900 | |
| C Overall Height(mm) | 1820 | |
| Engine | ||
| Engine Brand | Rato | |
| Max. Horsepower(HP) | 33 | |
| Cooling method | Air-cooled | |
| Fuel Type | Gasoline | |
| Fuel Grade | 92# | |
| Theoretical fuel consumption(L/h） | 10 | |
| Hydraulic system | ||
| Main pump model | PGP532B62 | |
| Max. flow rate of main pump(L/min) | 70 | |
| Tracks | ||
| Wheels | 570*16 | |
| Fuel tank | ||
| Fuel tank(L) | 40 | |
| Hydraulic oil tank(L) | 40 | |
Applications of KRW232 Wheel Loader
Landscaping and Garden Construction
Versatile groundwork capabilities make it ideal for soil management, tree transplantation, turf leveling, and garden bed preparation in parks, gardens, and green areas.
Gentle tracked operation prevents damage to delicate surfaces like lawns, moist soil, and wetlands.
Compact structure ensures easy access to confined spaces such as flower beds, courtyards, and urban green zones.
Residential and Small-Scale Construction
Supports diverse tasks including foundation digging, land grading, small-batch concrete mixing, and material transport.
Designed to reach restricted areas like basements, garages, and narrow worksites inaccessible to conventional machinery.
Agricultural and Facility Applications
Efficiently manages fertilizers, soil, feed, and light farm equipment in fields, greenhouses, and orchards.
Tracked chassis delivers reliable traction and stability on muddy or soft terrain.
Municipal and Infrastructure Services
Ideal for minor pipeline repairs, drainage maintenance, curbstone installation, and other public works.
Compact footprint minimizes disruption to streets and sidewalks while enabling flexible operation in tight urban spaces.
Light Demolition and Material Handling
Compatible with breakers and grapples for light demolition, waste clearance, and stacking tasks.
High maneuverability ensures rapid completion of small renovation and dismantling projects.
Indoor and Specialized Operations
Capable of working inside warehouses, factories, and underground parking lots for cleanup and logistics tasks.
Low noise and vibration output meets strict environmental standards for sensitive locations.
